3 Channel Laboratory Injection Pump - High Precision Microinjection Dispensing System with Syringe Booster for Cell Research, IVF, and Scientific Experiments

Package includes: 1 x Injection Pump 1 x Controller 1 x Adapter Size: 290mm*130mm*130mm Weight: 1.5kg Injection Pump 3 Channel Laboratory Microinjection Pump Dispensing Apparatus Syringe Booster Specifications: Clampable syringe: 1ml~50ml(Max)*3 (diameter <38mm) Speed range: continuously adjustable 0.1mm/h - 5940mm/h Time setting: 1 second to 17 hours Working mode: manual control, timed work, communication control Equipment working power: 12V 2A Adapter power supply: 100~240V/50Hz Motor length: 62mm; Slider stroke: 140mm; Single circle lead: 1mm Max pushing force: about 50N Features: In addition to the MM unit, the controller also contains the sizes of 1, 2, 5, 10, 20, 30, 50 ml syringes, and automatically switches to ML after selection8mm diameter stainless steel round guide rail is adopted, extended bearing with flange, the screw rod adopts T8 lead, 1mm screw, copper screw nut, clamping adopts pressing block, M4 hand nut fasteningThe motor is the 42 step motor, large torque motor is adopted, the single lap is set to 400 stepsController, 1602 liquid crystal display, 4 buttons can set speed, work time, work mode, and the other 4 buttons for controlling the machines, respectively, fixed speed movement and high-speed movementThe set parameter saves the power storage, quick press add button, BoardReserved TTL level RS-232 interface, the control button also has an external interface that can be used for interfacing switch off external switch and foot switch etc. you can connect external controllers such as computers and PLC Features: In addition to the MM unit, the controller also contains the sizes of 1, 2, 5, 10, 20, 30, 50 ml syringes, and automatically switches to ML after selection 8mm diameter stainless steel round guide rail is adopted, extended bearing with flange, the screw rod adopts T8 lead, 1mm screw, copper screw nut, clamping adopts pressing block, M4 hand nut fastening The motor is the 42 step motor, large torque motor is adopted, the single lap is set to 400 steps Controller, 1602 liquid crystal display, 4 buttons can set speed, work time, work mode, and the other 4 buttons for controlling the machines, respectively, fixed speed movement and high-speed movement The set parameter saves the power storage, quick press add button, BoardReserved TTL level RS-232 interface, the control button also has an external interface that can be used for interfacing switch off external switch and foot switch etc. you can connect external controllers such as computers and PLC Features: In addition to the MM unit, the controller also contains the sizes of 1, 2, 5, 10, 20, 30, 50 ml syringes, and automatically switches to ML after selection 8mm diameter stainless steel round guide rail is adopted, extended bearing with flange, the screw rod adopts T8 lead, 1mm screw, copper screw nut, clamping adopts pressing block, M4 hand nut fastening The motor is the 42 step motor, large torque motor is adopted, the single lap is set to 400 steps Controller, 1602 liquid crystal display, 4 buttons can set speed, work time, work mode, and the other 4 buttons for controlling the machines, respectively, fixed speed movement and high-speed movement The set parameter saves the power storage, quick press add button, BoardReserved TTL level RS-232 interface, the control button also has an external interface that can be used for interfacing switch off external switch and foot switch etc. you can connect external controllers such as computers and PLC Features: In addition to the MM unit, the controller also contains the sizes of 1, 2, 5, 10, 20, 30, 50 ml syringes, and automatically switches to ML after selection 8mm diameter stainless steel round guide rail is adopted, extended bearing with flange, the screw rod adopts T8 lead, 1mm screw, copper screw nut, clamping adopts pressing block, M4 hand nut fastening The motor is the 42 step motor, large torque motor is adopted, the single lap is set to 400 steps Controller, 1602 liquid crystal display, 4 buttons can set speed, work time, work mode, and the other 4 buttons for controlling the machines, respectively, fixed speed movement and high-speed movement The set parameter saves the power storage, quick press add button, BoardReserved TTL level RS-232 interface, the control button also has an external interface that can be used for interfacing switch off external switch and foot switch etc. you can connect external controllers such as computers and PLC Notes: Because of the different types of syringes installed, the design only takes into account the displacement and speed settings, in use, you need to use a ruler to measure the distance of the syringe, then calculate the speed of propulsion and get the corresponding velocity.About the position of the motor, according to the requirements of some users before, the shopkeeper designed the motor at the other end of the injector.Many customers have asked about the thrust of the problem, where the treasurer tested with a soil approach, you can pull 5 kilograms of weight, so you can thrust at about 50N.Note: it is not recommended to use it for electrospinning experiments!In addition to the MM unit, the controller also contains the sizes of 1, 2, 5, 10, 20, 30, 50 ml syringes, and automatically switches to ML ml after selection. Desktop Injection Pump Laboratory Microinjection Pump (3 Channel Set) Desktop Injection Pump Laboratory Microinjection Pump (Single Channel Set) Desktop Injection Pump Laboratory Microinjection Pump (Only Injection Pump) Add to Cart Add to Cart Add to Cart Customer Reviews 5.0 out of 5 stars 1 5.0 out of 5 stars 1 — Price $288.99$288.99 $268.99$268.99 $228.99$228.99 Model 3 Channel Set Single Channel Set Only Injection Pump
